High Efficiency Long Lifespan Triple Light LED Street Light Fixtures with 10kv 20kv Surge Protection
Item NO.: ZHSL-04-180
Production Description:
- Better LED ZHSL-04 series LED Street Lights adopt LED Chip with Cob 50w 60w 70w 80w / 100w 110w 120w/ 150w 160w 170w 180w encapsulation. LED efficiency is more than 130lm/w, and Life time is more than 70000hours.
- Bionic structure design, low wind resistance, excellent self-cleaning performance. Aluminum alloy die-casted. Double fins, efficient heat dispassion
- By using good quality CE and RoHS approved constant current LED driver, make sure the LED Chip life time.
- Anti-glare Glass Lens, Bat Wing Pattern beam angle,120° 130° 140° 150°available
Colorful housing White / Black / Gray / Blue / Red, other color upon request
Features:
1.LED Driver: External Meanwell / Inventronics driver
2.Warm and cold color temperature are available
3.Quick and easy installation to minimize retrofit costs.
4.Patented heat dissipation technology for radiator;
5.Aluminum ADC-3 for resistance to corrosion, seawater, oil and lubricant etc;
6.Acrylic sealing reflector around LED; anodized oxide treated aluminum reflector & acrylic reflector available;
7.Closed corrosion-proof silicone ring for dustproof and waterproof
8.Beam angle: 150x70 degree. Dustproof cover, or Crystal PC reflector available
9.Lamp surface treated with anodization, corrosion-resistant, shake-resistant and artistic appearance
10.Terrific heat dissipation technology: LED temperature will be rapid transfered to fin-style heatsink through heatpipe
11.Energy saving: Replace 400-500w traditional lamps, saving more than 80%
12.Eco-friendly: No lead, mercury, UV interference
13.Long lifespan: more than 50000 hours, If LED works 11-12 hours per day, it can work over 10 years.
14.Warranty: 5 years
Technical Datas:
| ITEM NO.: | ZHSL-04-180 |
| Power: | 150w/ 160w/ 170w/ 180w |
| LED Chip: | American CREE high power LED luminous source, with LM-80 test report, providing excellent lumen output and high CRI, is compatible with Bridgelux, Sharp, Nichia COB LED source as well |
| LED QTY: | 3pcs |
| LED Driver: | MeanWell / Inventronics optional (other brand of driver upon request); Class I or Class II upon request |
| Dimming: | Dali 1-10V PWM AstroDIM for autonomous dimming with five independent levels Smart control management system |
| Options: | Photocell Surge protection device (up to 20KV) 0.5m External cable(Other length upon request) Smart control device Motion detection |
| Standards & Certifications: | CE, ROHS, ENEC, GS, IEC, LM79, TM21 |
| Input Voltage: | AC 90-305V |
| Frequency: | 50/60Hz |
| Power Factor: | >0.95 |
| Total flux: | 150w: >19500lm 160w: >20800lm 170w: >22100lm 180w: >23400lm |
| Working temperature: | -40℃-50℃ |
| Working Humidity: | 20%-90% RH |
| Optic angle: | 150°* 70°, other optic angle optional |
| Color Rendering Index: | Ra>70 |
| Color Temperature: | 2700-6500K |
| Life Span: | ≥70000h |
| Protection Grade: | IP66/IK09 |
| Installation Pipe Diameter: | Φ60mm |
| Installation Height: | 10-15m |
| Product Dimension: | 950*347*155mm |
| Net Weight: | 10.5KG |
| Gross Weight: | 12.5KG |
| Packing Size: | 1005*400*210mm |
Detailed Features:
Manufacturing Processes
Light Distribution Curve:
High quality glass lens, light transmission rate of 95%, higher than ordinary PC and PMMA lens; and high temperature, the softening and aging problem does not occur, stable performance; and good light distribution to form a wide bat-wing lighting effects and good lighting uniformity.
Aging Test: After safe test and lighting test, will be the aging test, aging test will last for 24 hours.
Application:
Car Park & Intersection
Caravan & Holiday Parks
Council & Government
Jetties & Coastal
Mining & Industrial
Pathway. Bike Trail & Minor Road
Public Spaces & Parks
Rural & Off Grid
Security & Safety
Smart Lighting
Why us?
1) We are not only a die casting factory, but also a factory consist of a completed lighting design team, tooling and mold development workshop, auto-painting finishing lines, assembly lines, and completed lighting products testing.
2) All of the material and finished products will be tested under the ISO9001 quality control system.
3) We have many advanced equipments, such as semi-automatic die cast machines, CNC treatment, and full sets of completed lights IP testing, lumen test ,aging test, and photometric testing equipments. All those facilities make sure the quality is approved by CE, RoHS, TUV certificate.
4) Our team develops new items every year according to different market’s style. The products rang is including LED street light, LED urban light, LED High bay light and LED tunnel light. Our new patent design of led street lights is very popular in the market.
5) In order to meet more and more requirements of customers, we offer ODM and OEM good service. Welcome to contact the sales and visit Zhouhua factory to discuss face to face.
